USB 2.0 Hi-Speed (480Mb/s). Uses FTDI FT2232HQ chip. This board breaks out all connections from chip to connectors.
2 Independent USB to serial ports. Supported JTAG debugger in OpenOCD, urJTAG, and others
2 MPSSE modules with I2C, SPI, and JTAG
General purpose IO pins Connected to two 13x2 Headers
Please visit the FTDI Dual Channel Breakout Board product page under the earthpeopletechnology website to access all schematics, user manual, and data sheets.
FTDI Breakout Board Dual Channel
Reviews
4.2
All from verified purchases
N**S
nice breakout - easy to reprogram EEPROM for JTAG
Bought this to use for JTAG program of TI C2800 based hardware. Using ftprog able to update the EEPROM for use in CCS.
