HENG’S INDUSTRIES Typhoon Upgrade Kit | Roof Vent Fan Motor Replacement | 12V | Compatible with Heng's & Ventline Style Vents | 90057-CR

I bought this Heng 90046-CR Replacement Vortex II Fan to upgrade the existing vent in my Aliner Sportliner camper (the smallest of the Aliner models). That vent had never had a fan and had no original wiring. From other reviews, installation videos, and Amazon Q&As, I thought the Heng unit should fit the vent but was not sure if it would run well in the severely slanted Aliner roof. I was also concerned about clearance for the fan profile when my Aliner was closed. My results were good. The Heng unit fit the existing opening, and the vent control system worked with the Heng control adapter. I pulled power from a light fixture located lower on the wall after testing the polarity of the existing two wire system (both Aliner wires were black) and that of the fan (one black wire, one white wire, but not wiring diagram provided). I surface mounted those wires on my slant ceiling in a low profile, self-adhesive cord cover and drilled a small hole in the face of the Heng to be able to route my power to the Heng wires at the back of the fan. The Heng fan runs without difficult at the roof angle of the Aliner and moves air very well. It was great for creating air movement on hot days. On cold days, with the vent closed, the unit pushes warm air back from the peak of the ceiling to recirculate it, reducing the amount of run-time for the furnace and evening the temperature throughout the living space. Unlike the vent fan models used as original equipment for the Aliner, the Heng profile does cause concern when folding the roof to its closed position. There is no question that the control handle for the vent would be smashed if it were not removed before roof closing. The removable screen which covers the fan also seems wise to relocate before closure. The fan speed control knob and other elements of the face of the fan can be bypassed if care is taken when collapsing the roof components and, so far, have not been damaged during closed-roof transport, but these parts seem at risk of eventual damage. I will probably make it a practice to remove the entire insert when it is necessary to close my roof or eventually adapt the depth of the Heng so the projections are protected in the vent cavity. If I always had a companion to assist when the roof halves are moving, I'd probably use the Heng as is and address any problems if they occur. My previous RV vent fan experience has been with professionally installed Fantastic Vent Fans (original manufacturer, not current). Given the price difference and ease of aftermarket installation (watch the videos as there are several tips which are helpful), this Heng unit compares well. I will be buying another for a flat roof camper application this coming season.

I bought and installed in my Catalina Coachman travel trailer. It was easy to install and works great. It was easy to install went right back in the the OEM. There are even Youtube videos on how to install. It is a little bit louder but really moves the air and it can exhaust out or pull air in. There is even a High, Medium, and Low setting. (The low setting is similar in sound as the OEM small fan sound but even at the low moves a ton of air. I will buy again.

Super easy install EXCEPT it is such a precise fit that I had to do modifications to factory parts on trailer. My trailer (new) had factory wimpy, loud, tiny, one direction fan motor. Read about this upgrade and ease of install. Easy to change the position of the gear (in new housing) to engage that in cover mechanism (two screws, designed for this and much appreciated). However, trying to push the new unit up into old housing after removal of old motor revealed obstruction at corners and no amount of jiggling and changing angle of insertion allowed it to seat properly. Took awhile to diagnose and resolve. The opening in roof (after removal of cover plate) is reinforced at each corner by a bracket spanning the thickness of the roof, curved (concave) to allow the new fan housing (square shape with rounded corners) to fit with very tight tolerance. Unfortunately, the little screw clips at corners of upper brackets that hold long bolts vertical projected about 1 mm each into the available space. This was enough to prevent proper seating of the new fan. So, I removed each long bolt one at a time, shaved the projecting 1 mm off each screw clip, and replaced (careful not to crush roof with too much tightening). New unit then fit perfectly and runs great. Not a fault of new fan manufacture, but no one else mentioned this issue (my trailer is a Lance). Super great mod. Noticeably noisier than Fantastic fan, but quieter than old fan and with adjustable speeds and reversible. LOVE IT! One suggestion--recommend a label for knob that raises/lowers outside vent cover that reminds us which direction to rotate for open vs close. I drew on with marker...

The 1st one delivered (DIFFERENT SELLER) had 2 problems: 1) the LOW speed did not work, and 2) the plastic housing for the motor was cracked in two places. No big deal, but had to order a 2nd unit and do a return. The 2nd unit was fine. I really liked being able to do the install 100% from the inside, using existing screw holes. In our RV, we have a walkaround queen bed with a vent above it. The vent did not have a fan at all, and we wanted to add one. This fan installed very easily into our vent opening. As luck would have it, 12v DC power lines were running right by the opening already for nearby ceiling lights, and it was very easy to tap into it. I used my own WAGO lever nuts instead of the provided old school wire nut: I just find them easier to work with. The fan works fine, although I will say in my (hearing-impaired) opinion it is rather loud on the MEDIUM or HIGH settings, and the LOW setting is only available for one direction, not both. PRO TIP: our primary desire was to mimic our home ceiling fan above our bed. We want it to blow down on us from outside, and we also don't want a lot of noise. Consequently, I switched the polarity on the wires so the LOW setting will blow down on us from outside.

Pièce lousse dans la boîte et manquante , comme s’il n’était pas complètement construit…. Je le retourne et en commande un autre , en espérant que le prochain sera ok .

Love this fan. Lost more air flow than the factory one and you don’t have to do anything on the roof. Easy install go a DIY person.

Slow delivery. Was missing the accessories bag with the various screws and most importantly the vent lid knob and spacer. The seller sent that quickly. The item itself was a fairly easy install if you're a bit handy. A big improvement over the standard tiny "toy" fan that was originally there. A bit noisy but it's moving a lot more air and it's in the toilet/shower room that needs it the most! I recommend it.

Our camper has two roof vents, one has no fan and one has a useless fan. We put a big brand name one into the one that had no fan in the main living area. It took a while day - removal of the old unit was 90% of the work. I didn't want to go through that again but just wanted some air movement so I checked out YouTube and this was suggested. Had I known how freaking easy it was to install, for a sixth of the price, I would never have put in that other unit! This goes in with ease and without having to go on the roof and strip dicor for hours. The power to the fan hooked up easily and I had it up and running, alone, in less than 30 minutes. The airflow is fantastic. Get this, you can do it and you won't regret it!

My trailer did not come with a fan installed from factory. This unit fits perfectly. It fits like factory installed. I installed in bathroom vent of a Jayco 174bh. I ran power from the light near by. Install was relatively easy, but you need to figure out your own 12v wiring for the unit. The included wires are short, so you will need a spool of wire to extend somewhere for your power and ground. I will be buying another for the kitchen vent, as I am very happy with this unit. Works perfectly for the past year. 3 speed fan, with 2 reverse speed settings. Screen removes easily for cleaning.
